The TOP Server® Fanuc Focas Suite provides the ultimate in flexibility for connectivity to the widest range of devices supporting the Fanuc Focas protocols and integration to other software applications using OPC DA, OPC UA and AVEVA Suitelink. This software provides communications with multiple protocol networks including Fanuc Focas Ethernet and Fanuc Focas HSSB.
The TOP Server supports the Focas 1 or the Focas 2 interface libraries that are available from FANUC America Corporation. (The Focas2 Library combines both Ethernet and HSSB capabilities.) This software may be obtained from a FANUC distributor, or by calling 1-888-FANUC-US (1-888-326-8287).
Communication
Protocols Supported
Fanuc FOCAS (FANUC Open CNC API Specification)
Connection Types
Ethernet TCP/IP, HSSB (High Speed Serial Bus)
Max Devices per Channel
1024 channels & 128 devices per channel (Ethernet) / 4 devices (HSSB)
Everything you need to get started, configure, and troubleshoot your driver
TOP Server How-To Videos / Tutorials
Main landing page with a library of how-to videos covering installation, general overview, troubleshooting tools, driver quick starts, and other TOP Server configuration topics
TOP Server How-To Application Notes
Support knowledge base with application notes, guides, and FAQs for TOP Server
TOP Server Quick Start Guide
Getting started guide covering TOP Server basics, installation, and sample projects
TOP Server Troubleshooting Guide
Comprehensive troubleshooting documentation for resolving common issues
TOP Server Fanuc Focas Ethernet Driver Help File
Complete Ethernet driver documentation and configuration guide in PDF format
TOP Server Fanuc Focas HSSB Driver Help File
Complete HSSB driver documentation and configuration guide in PDF format
TOP Server Data Sheet
Product overview and technical specifications
Current/Past Release Notes
View the complete TOP Server release history and version information
TOP Server License Agreement
End user license agreement and terms of use
Supported Devices
- ✓FANUC Series 0i
- ✓FANUC Series 15
- ✓FANUC Series 15i
- ✓FANUC Series 16
- ✓FANUC Series 16i
- ✓FANUC Series 18
- ✓FANUC Series 18i
- ✓FANUC Series 21
- ✓FANUC Series 21i
- ✓FANUC Series 30i
- ✓FANUC Series 31i
- ✓FANUC Series 32i
- ✓FANUC Power Mate i
- ✓Open Addressing
Supported Protocols
- ✓FOCAS Ethernet
- ✓FOCAS HSSB (High Speed Serial Bus)
- ✓TCP/IP Ethernet
Available Languages
- ✓English
- ✓Simplified Chinese (Fanuc Focas HSSB OPC Driver only)
Note: For a complete list of supported models and firmware versions, please contact our technical support team or download the driver documentation.
Everything you need for reliable industrial connectivity
Dual Interface Support
Connect via Ethernet TCP/IP or HSSB (High Speed Serial Bus) for maximum flexibility and compatibility
Comprehensive CNC Data Access
Access machine status, program execution, axis positions, alarms, tool offsets, work coordinates, and more
OEE & Production Monitoring
Real-time data collection enables OEE calculation, production tracking, and performance optimization
Fanuc FOCAS API
Built on official Fanuc FOCAS (FANUC Open CNC API Specification) library for reliable communication
