DNP 3 Suite TOP Server - Unlimited devices license And IO Driver + 1 Year Support & Maintenance Agreement
- Details
- Why Choose This Driver?
- Technical Specifications
- Resources and Documentation
- Supported Devices
- Key Features & Benefits
- Advanced Features
The TOP Server DNP3 (with SAv3 and SAv5 authentication) Client OPC Drivers Suite provides a communication interface for RTUs, outstations, IEDs, and controllers supporting the DNP3 protocol over Ethernet TCP/IP and Serial RS-232/485 for utility SCADA and automation control.
The DNP3 Client Ethernet and DNP3 Client Serial drivers work in conjunction with TOP Server's OPC DA, OPC UA & AVEVA Suitelink client interfaces to provide connectivity and communications with HMI, SCADA, MES and Historian client applications.
The driver suite is also available in a lite version for up to 10 devices for tight budgets. Click here for more information.
Proven benefits that help you deploy faster and operate more reliably
Utility SCADA Integration
Seamlessly integrate DNP3 outstations with modern SCADA systems and HMI applications
Industry Standard Protocol
Leverage the widely adopted DNP3 protocol used across electric utilities, water/wastewater, and oil & gas
File Transfer Support
Transfer files and large data sets between master and outstation devices
Complete Suite Solution
Both Ethernet and Serial drivers included in one package for comprehensive DNP3 connectivity
Communication
Protocols Supported
DNP3.0 (Distributed Network Protocol Version 3.0)
Connection Types
Ethernet TCP/IP, Serial RS-232/485
Max Devices per Channel
256 channels, configurable devices per channel
Everything you need to get started, configure, and troubleshoot your driver
TOP Server How-To Videos / Tutorials
Library of how-to videos covering installation, configuration, and troubleshooting
TOP Server How-To Application Notes
Support knowledge base with application notes and guides
TOP Server Quick Start Guide
Getting started guide covering TOP Server basics and installation
TOP Server Troubleshooting Guide
Comprehensive troubleshooting documentation
DNP3 Client Ethernet Driver Help File
Complete Ethernet driver documentation in PDF format
DNP3 Client Serial Driver Help File
Complete Serial driver documentation in PDF format
Current/Past Release Notes
View the complete TOP Server release history
Supported Devices
- DNP3 RTUs (Remote Terminal Units)
- DNP3 Outstations
- DNP3-compliant PLCs
- Utility meters with DNP3
- Substation automation devices
- Protection relays with DNP3
- Any DNP3 Level 1 or Level 2 compliant device
Supported Protocols
- DNP3 over Ethernet TCP/IP
- DNP3 over Serial (RS-232/485)
Note: For a complete list of supported models and firmware versions, please contact our technical support team or download the driver documentation.
Everything you need for reliable industrial connectivity
Dual Interface Support
Connect via Ethernet TCP/IP or Serial RS-232/485 for maximum flexibility and compatibility
DNP3 Level 2 Compliant
Full DNP3 Level 2 implementation with support for binary, analog, and counter data types
Unsolicited Responses
Supports unsolicited response messages for event-driven data updates from outstations
Time Synchronization
Built-in time synchronization capabilities for accurate timestamping across devices
- Configurable Scan Rates – Exception-based polling and configurable scan rates for optimal data collection
- Time Synchronization – Built-in time synchronization capabilities for accurate timestamping across devices
- DNP3 Security (SAv2/SAv5) – Support for DNP3 Secure Authentication v2 and v5 for secure communications
- Object Library Support – Extensive object support including Binary, Analog, Counter, and Octet String types
